EcoFlow 500W Alternator Charger

EcoFlow 500W Alternator Charger, charge while you drive, and stay powered up on the road.

500W alternator charger, 5x faster than traditional in- vehicle auxiliary power outlets. 500W(45A@12V*) input, 2.1 hrs to fully charge 1kWh (85Ah@12V).

Key Features:

- A 3-in-1 fast charger, maintainer, and jump starter keeps your battery in mint condition.
- Third party portable power stations are applicable.
- 3-step easy installation.

Charging Mode
Use your car's alternator to refuel your portable power station.

Reverse Charging Mode
Recharge your vehicle starter battery or RV house battery using your portable power station.

Battery Maintenance Mode
Extends your vehicle starter battery or RV house battery life by using a lower electrical current.

Compatible with all EcoFlow and most third-party power stations
Compatible with an XT60 connection, designed to charge EcoFlow RIVER, DELTA Series, and most third-party power stations. The charger's 500W fast-charging is compatible with most SUV, Pickup, and RV alternators, meeting diverse short-trip car camping power needs.

*When using an XT60 cable, the Alternator Charger switch on the device must be manually turned on and the charging function enabled in the app before charging can begin. Therefore, if planning to use the XT60 cable for output, avoid concealed

Specifications

Net Weight: 1.6kg

Dimensions (W × D × H): 242 x 194 x 35 mm

Connection type: Wi-Fi & Bluetooth

Charge Mode:

- Input: 12V/24V?(11V-31V?), 45A Max

- Output:40V-60V?, 500W Max ; 24V?, 360W Max

Battery Maintenance Mode:

- Input: 40V-60V?, 3A Max

- Output: 13.8V/27.6V?, 100W Max

Reverse Charge Mode:

- Input: 40V-60V?, 13.2A Max

- Output: 13.8V/27.6V?, 500W Max

Rated Current of Fuse: 125A

Protection Type: Reverse polarity protection, Overcurrent protection, Short circuit protection, Overvoltage and undervoltage protection

(Provided with integral protection against overloads)

Operating Temperature: -20°C to 60°C*

Storage Temperature: -30°C to 70°C

Operating Humidity: 95%

Storage Humidity: 95%

 installation of the Alternator Charger in advance.

 * Not Suitable for engine bay installation
